This text book is intended for under-graduate Engineering and/or IT students studying micro-controllers and embedded systems. It covers mainly the C8051F020 family of mixed signals micro-controllers from Silicon Laboratories IDE (http://www.silabs.com). Starting with the basic architecture it then moves on to explain the PaulOS_F020 co-operative Real-Time Operating System (RTOS) with full source code listing. This is derived from the self-developed basic 8051 RTOS fully described in my previous 2-part Bookboon book ‘PaulOS – An 8051 RTOS’ but specially modified for the high performance Silicon Lab MCU. Various example application programs using the Keil IDE (http://www.keil.com) and/or the Silicon Labs ‘Simple Studio’ are given as well as useful hints to avoid programming pitfalls.
Description
Content
- C8051F020 Basics
- Introduction
- Memory Types
- Program/Data Memory (Flash)
- External Data Address Space (XRAM)
- Register Banks
- Bit Memory
- Special Function Register (SFR) Memory
- SFR Descriptions
- PaulOS F020: a co-operative RTOS
- Description of the RTOS Operation
- PaulOS_F020.C System Commands
- Descriptions of the commands
- PaulOS_F020_Parameters.h header file
- Example using PaulOS_F020 RTOS
- Master – Slave RTOS
- Multi-controller RTOSs
- Master
- Slave
- Programming Tips and Pitfalls
- RAM size
- SFRs
- Setup faults
- Serial ports (UART0 and UART1)
- Interrupts
- RTOS pitfalls
- C Tips
